Economy Folding T-Handle with Holes (Black)

Economy Folding T-Handle with Holes (Black)

10502-CH510-BLK

$16.94 AUD
$33.00 AUD $16.94 AUD
Sale Out of Stock
Prices include 10% GST. Shipping calculated at checkout.
Orders will dispatch within 2 business days. Click & Collect available (Tullamarine,VIC)

Prices include 10% GST. Shipping calculated at checkout.
Orders will dispatch within 2 business days. Click & Collect available (Tullamarine, VIC)

Features:

  • Suitable for single or multi-point locking
  • 2x cam & key types available:
    • Bent cam (+9mm), 001 key (w/o dust cap) (adjustable H= dimension)
    • Flat cam (0mm), CH510 key (w/ dust cap)
  • Front fixing, 5mm holes
  • Mild steel, matte black powder coated dish w/ chrome plated handle
  • Foam gasket included
  • Suitable for hole mounting

Dimensions:

  • Height:  125mm (flat cam)
  • Height:  124mm (bent cam)
  • Width:  121mm
  • Mounting Hole Measurements:  99mm (left to right), 84mm (top to bottom)
  • Adjustable flat cam (H=):  30mm to 46mm
  • Adjustable bent cam (H=):  38mm to 60mm

Material & Finish:

  • Handle:  Zinc die-cast, chrome plated
  • Bracket:  Zinc die-cast, zinc plated
  • Dish:  Mild steel, black powder coated
  • Cam & shaft:  Mild steel, zinc plated

Accessories:

  • Pins for rods:  10502-PIN
  • Rods:  ROD###E
